PRODUCT INFORMATION:

Introducing the RDO DIGITAL, featuring a new and improved design with digital limits that makes commissioning easier and more convenient than ever before. Enjoy fast and simple setup without compromising on reliability and performance.

No More Struggling with Mechanical Limits

Tired of the tedious task of manually adjusting limits on garage door operators? The RDO DIGITAL offers an effortless and efficient solution. Our new digital limit system allows you to conveniently program the motor directly from the Controller.

7-Segment Display

The RDO DIGITAL’s 7-segment display further simplifies commissioning and configuration.

What’s new for garage door users?

We’ve equipped the RDO DIGITAL with a built-in LED courtesy light that illuminates your garage space during operation. Enjoy enhanced visibility and peace of mind, even in low-light conditions, in addition to reliable battery-driven technology for uninterrupted access during power outages.

TECHNICAL SPECIFICATIONS:

• Input voltage: 220V AC +/- 10% @ 50Hz1
• Motor voltage: 24V DC
• Motor power supply - rated: 120W DC
• Motor supply: Battery-powered with 2 x 1.3Ah 12V batteries and 300mA charger
• Maximum door width: 2.8 meters
• Maximum door area: 10 meters²
• Maximum lifting capacity: 20kg
• Operations in standby mode: 12 to 20 cycles, dependent on door size, weight, height and duration of power failure
• Operator travel speed: 110 to 150mm/sec, dependent on door weight
• Door travel adjustment: Digitally-adjustable limits
• Safety obstruction force system: Automatic with adjustable offset
• Light : LED
• Onboard receiver type: NOVA code-hopping (single channel)
• Receiver code storage capacity: 20 remotes2
• Receiver frequency: 433Mhz

What's in the box
1x Centurion RDO Digital Power Head
1x Centurion Control Unit
2x Centurion 4 Button Remotes
1x Counter weight
2x 1.4ah Battery
User Manuals and Instructions
