PRODUCT INFORMATION
Records only when you want it to
The C1C-B camera provides a flexible option for you to record – or not – whenever you think it’s necessary. You can manually activate the Sleep Mode with a tap on your phone, at which you won’t receive notifications and real-time recording will pause.
SPECIFICATIONS OF THE EZVIZ C1C-B 1080p Full HD WiFi IP Indoor Camera Twin Pack CAMERA:
| Model | CS-C1C-B (1080P) |
|---|---|
| Version | E0-1E2WF |
| Camera | |
| Image Sensor | 1/3" Progressive Scan CMOS |
| Shutter Speed | Self-adaptive shutter |
| Lens | 2.8 mm, view angle: 108° (Diagonal), 91° (Horizontal), 50° (Vertical) |
| Minimum Illumination | 0.5 Lux @(F2.2, AGC ON), 0 Lux with IR |
| Lens Mount | M12 |
| Day & Night | IR-cut filter with auto-switching |
| DNR | 3D DNR |
| Night Vision | 12 m |
| Video & Audio | |
| Max. Resolution | 1920 × 1080 |
| Frame Rate | Max: 25 fps; Self-Adaptive during network transmission |
| Video Compression | H.265 |
| H.265 Type | Main Profile |
| Video Bit Rate | Full HD; Hi-Def; Standard. Adaptive bit rate. |
| Audio Bit Rate | Self-Adaptive |
| Max. Bitrate | 1 Mbps |
| Function | |
| Smart Alert | Motion detection |
| Two-way Talk | Supports |
| General Function | Anti-Flicker, Dual-Stream, Heart Beat, Mirror Image, Password Protection, Watermark |
| Network | |
| Standard | IEEE802.11b, 802.11g, 802.11n |
| Frequency Range | 2.4 GHz ~ 2.4835 GHz |
| Channel Bandwidth | Supports 20 MHz |
| Security | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK |
| Transmission Rate | 11b: 11 Mbps, 11g: 54 Mbps, 11n: 72 Mbps |
| Wi-Fi Pairing | AP pairing |
| Protocol | EZVIZ cloud proprietary protocol |
| Interface Protocol | EZVIZ cloud proprietary protocol |
| Storage | |
| Local Storage | MicroSD card slot (Max. 256 GB) |
| Cloud Storage | EZVIZ Cloud Storage |
| General | |
| Operating Conditions | -10 ºC ~ 45 ºC (14 °F ~ 113 °F ), Humidity 95% or less (non-condensing) |
| Power Supply | DC 5V / 1A |
| Power Consumption | MAX. 3.0 W |
| Dimensions | 63 × 63 × 103 mm (2.48 × 2.48 × 4.06 inch) |
| Packaging Dimensions | 91.5 × 87.5 × 149 mm (3.60 × 3.44 × 5.87 inch) |
| Net Weight | 83 g (2.93 oz) |
| Weight (With Package) | 310 g (10.93 oz) |
| In the box | |
| In the box | - C1C-B Camera |
| - USB Cable | |
| - 3-Meter Power Adapter | |
| - Foam Sticker | |
| - Metal Plate | |
| - Regulatory Information | |
| - Quick Start Guide | |
| Certificates | |
| Certifications: | FCC / UL / CE / RoHS / WEEE / REACH |
WHAT'S IN THE TWIN PACK:
| -X2 C1C-B Camera | |
| -X2 USB Cable | |
| -X2 3-Meter Power Adapter | |
| -X2 Foam Sticker | |
| -X2 Metal Plate | |
| -X2 Regulatory Information | |
| -X2 Quick Start Guide | |
