PRODUCT INFORMATION
The Ezviz C6N WiFi Pan/Tilt 2MP camera comes equipped with a Smart IR function, which uses advanced infrared (IR) lighting to capture more details in dim light. With its 360-degree field of view and smart tracking function, you won’t need to worry about missing a thing.
CS-C6N-BO-1GWF-EZVIZ C6N
FEATURES OF THE EZVIZ C6N WIFI PAN/TILT 2MP CAMERA:
- Wi-Fi PT Camera
- 2MP Resolution
- 4mm Fixed Lens
- Stand-alone Camera
- Motorized Pan and Tilt 360° Visual Coverage
- Two-way Audio
- Smart Night Vision with Smart IR
- Smart Motion Tracking (Detect and Follow)
- Sleep Mode for Privacy Protection
- Micro SD Card Support (up to 256 GB)
- Power Source 5VD
- Remote Access – Live View from Ezviz App
SPECIFICATIONS OF THE EZVIZ C6N WIFI PAN/TILT 2MP CAMERA:
| CAMERA | |
| Image Sensor | 1/4" Progressive Scan CMOS |
| Shutter Speed | Self-adaptive shutter |
| Lens | 4mm@ F2.4, view angle: 85° diagonal, 75° horizontal, 45°vertical |
| Lens Mount | M12 |
| Day & Night | IR-cut filter with auto-switching |
| DNR | 3D DNR |
| WDR | Digital WDR |
| VIDEO | |
| Video Compression | H.264 |
| Video Bit Rate | Adaptive bit rate |
| NETWORK | |
| Smart Alarm | Motion detection |
| Wi-Fi Pairing | AP paring |
| Protocol | Ezviz Cloud proprietary protocol |
| Interface Protocol | Ezviz Cloud proprietary protocol |
| WI-FI | |
| Standard | IEEE802.11b/g/n |
| Frequency Range | 2.4 GHz ~ 2.4835 GHz |
| Channel Bandwidth | Supports 20MHz |
| Security | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK |
| Transmission Rate | 11b: 11 Mbps, 11g: 54 Mbps, 11n: 72 Mbps |
| IMAGE | |
| Max. Resolution | 1920 × 1080 |
| Frame Rate | Max. 15fps; Self-adaptive during network transmission |
| INTERFACE | |
| Storage | MicroSD card slot (Max. 256GB) |
| Power | Micro USB |
| Wired Network | RJ45 X 1 (10M/100M self-adaptive Ethernet port) |
| GENERAL | |
| Power Supply | DC 5V/1A |
| Power Consumption | 5W max |
| IR Range | MAX. 10m |
| Operating Environment | Temperature: -10° C to 45° C , Humidity: 95% or less (non-condensing) |
| Certifications | FCC / UL / CE / WEEE / REACH / ROHS |
| Product Dimensions | 88mm x 88.2mm x 119mm |
| Product Weight | 218g |
| Packaging Dimensions | 103mm x 103mm x 168mm |
| Mass of unit packed | 600g |
| Warranty | 12 months limited Manufacturer’s warranty |
PLEASE NOTE: NO MICRO SD CARD INCLUDED WITH THE C6N WIFI PAN/TILT 2MP CAMERA.
WHAT’S IN THE BOX:
1 x C6N 2MP camera
1 x Base
1 x Screw Kit
1 x Power Cable 3m (9.8 ft.)
1 x Drill Template
1 x Power Adapter
1 x Quick Start Guide
