PRODUCT INFORMATION
SPECIFICATIONS ON EZVIZ EZVIZ EB8 Pro 4G 4K PT Wi-Fi Camera:
| Specifications | ||
|---|---|---|
| Model | CS-BC1c-R100-2F8WFL | |
| Camera | ||
| Image Sensor | 1/2.7” 8-Megapixel Progressive Scan CMOS Sensor | |
| Minimum Illumination | 0.01 Lux @(F1.6, AGC ON), 0 Lux with IR | |
| Shutter Speed | Self-adaptive shutter | |
| Lens | 2.8mm@ F1.6; 135° (Diagonal), 113° (Horizontal), 60° (Vertical) | |
| Day & Night | IR-Cut filter with auto-switching | |
| DNR | 3D DNR | |
| Night Vision | IR Distance:15m, Color Night Vision Distance:15m | |
| Video & Audio | ||
| Max. Resolution | 3840*2160/4K/8MP | |
| Frame Rate | 15fps. Self-Adaptive during network transmission | |
| Video Compression | H.265 / H.264 | |
| Video Bit Rate | Ultra HD; Quad HD; Full HD; Hi-Def Adaptive bit rate. | |
| Audio Bit Rate | Self-Adaptive | |
| Max. Bitrate | 4 Mbps | |
| Network | ||
| Bluetooth | Supports | |
| Wi-Fi Standard | IEEE802.11b, 802.11g, 802.11n, 802.11ax | |
| Frequency Range | 2.4 GHz ~ 2.4835 GHz | |
| Channel Bandwidth | Supports 20 MHz | |
| Security | WPA-PSK/WPA2-PSK, WPA3-Personal | |
| Transmission Rate | 11b: 11Mbps, 11g: 54Mbps, 11n: 72Mbps, 11ax: 114Mbps | |
| Wi-Fi Pairing | AP pairing | |
| Protocol | EZVIZ cloud proprietary protocol | |
| Interface Protocol | EZVIZ cloud proprietary protocol | |
| Minimum Network Requirement | 8Mbps | |
| Function | ||
| Smart Alarm | AI-Powered Human Shape Detection, AI-Powered Vehicle Detection | |
| Two-way Talk | Supports | |
| General Function | Anti-Flicker, Heart Beat, Password Protection, Watermark | |
| General | ||
| Operating Conditions | -20 °C to 50 °C (-4 °F to 122 °F ), humidity 95% or less (Non-condensing) | |
| IP Grade | IP65 | |
| Power Supply | DC 5V/2A (Compatible power adapter needs to be purchased separately) | |
| Battery Capacity | 10400 mAh | |
| Power Consumption | Max. 10W | |
| Product Dimensions | 149.33 x 62.95 x 62.95 mm | |
| Packaging Dimensions | 103 x 103 x 186 mm | |
| Weight |
Net Weight: 348g With Package: 671g |
|
WHAT'S IN THE BOX:
| EZVIZ BC1c Camera |
| - Magnetic Base |
| - Screw Base |
| - USB Cable |
| - Pin |
| - Drill Template |
| - Screw Kit |
| - Regulatory Information |
| - Quick Start Guide |
