PRODUCT INFORMATION
Home protection in the simplest way.
If you are seeking for a simple, durable camera to tackle multiple security needs at a super affordable price, the C3TN can’t be beat. The camera is well-engineered to focus on the most needed features to get the basics right, including great video quality, extended night vision, weatherproof housing, and more.
Crisp 1080p video with extended night vision.
Say goodbye to blurry or pixelated footage. With the EZVIZ C3TN, you can view and record everything in Full HD 1080p to capture sharper, more vivid details. The camera also features two IR lights to render clear night vision up to 30 meters.
Stands up to even extreme weather.
With an IP67-rated camera body, the C3TN is both dust- and water-resistant. It can stand steady even against the toughest weather conditions – whether it’s rainy, stormy or snowy.
It’s your eyes – and ears.
The C3TN comes with a built-in noise-canceling microphone, which can pick up clear audio in the surrounding area. You can see and hear what’s going on in your backyard or at your front door at any time.
FEATURES OF THE EZVIZ EZVIZ C3TN Color - Wi-Fi Smart Home Camera:
SPECIFICATIONS OF THE EZVIZ C3TN Color - Wi-Fi Smart Home Camera:
| CAMERA | CS-C3TN(2MP) |
| Image Sensor | 1/2.7”Progressive Scan CMOS |
| Shutter Speed | Self-adaptive shutter |
| Lens | 2.8 mm @ F2.0, view angle: 106° (Horizontal), 122°(Diagonal) |
| Lens Mount | M12 |
| Minimum Illumination | 0.01 Lux @ (F2.0, AGC ON), 0 Lux with IR |
| DNR | 3D DNR |
| WDR | Digital WDR |
| VIDEO | |
| Video Compression | H.264 |
| Video Bit Rate | Ultra-HD; HD; Standard. Adaptive bit rate. |
| NETWORK | |
| General Function | Anti-Flicker, Dual-Stream, Heart Beat, Password Protection, Watermark |
| Wi-Fi Pairing | AP paring |
| Protocol | Ezviz Cloud proprietary protocol |
| Interface Protocol | Ezviz Cloud proprietary protocol |
| WI-FI | |
| Standard | IEEE802.11b, 802.11g, 802.11n |
| Frequency Range | 2.4GHz ~ 2.4835 GHz |
| Channel Bandwidth | Supports 20MHz |
| Security | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK |
| Transmission Rate | 11b: 11Mbps,11g: 54Mbps,11n: 144Mbps |
| IMAGE | |
| Max. Resolution | 1920 × 1080 |
| Frame Rate | Max: 30fps; Self-Adaptive during network transmission |
| INTERFACE | |
| Storage | MicroSD card slot (Max. 256GB) |
| Wired Network | RJ45 X 1 (10M/100M self-adaptive Ethernet port) |
| GENERAL | |
| Power Supply | DC 5V/1A |
| Power Consumption | 6W max |
| Night Vision Distance (Black/White Night Vision Mode) | Max. 30 m (98 ft) |
| Operating Environment | -4°F to 122 °F (-20ºC to 50ºC ); Humidity 95% or less ( non-condensing) |
| Certifications | CE / FCC / UL / RoHS / WEEE |
| Product Dimensions | 72 × 72 × 152 mm (2.83 × 2.83 × 5.98 inch) |
| Product Weight | 253g |
| Packaging Dimensions | 227 × 100 × 92 mm (8.94 × 3.94 × 3.62 inch) |
| Mass of unit packed | 270g |
| Warranty | 12 months limited Manufacturer’s warranty |
WHAT’S IN THE BOX:
| C3TN Camera |
| - Drill Template |
| - Screw Kit |
| - Waterproof Kit |
| - Power Adapter |
| - Regulatory Information |
| - Quick Start Guide |
