PRODUCT INFORMATION
CS-BC1C
SPECIFICATIONS OF THR EZVIZ CS-C3TN (3MP) WI-FI CAMERA:
| CAMERA PARAMETERS | CS-C3TN (3MP) |
| Image Sensor | 1/2.7”Progressive Scan CMOS |
| Minimum Illumination | 0.01 Lux @ (F2.0, AGC ON), 0 Lux with IR |
| Shutter Speed | Self-adaptive shutter |
| Lens) | 2.8 mm @ F2.0, view angle: 109° (Horizontal), 126°(Diagonal). |
| Lens Mount | M12 |
| Day & Night | IR-cut filter with auto switch 30M IR |
| DNR | 3D DNR |
| WDR | Digital WDR |
| VIDEO & AUDIO | |
| Max Resolution | 2304 × 1296 |
| Frame Rate | Max: 30fps; Self-Adaptive during network transmission |
| Video Compression | H.265 / H.264 |
| Video Bit Rate | Quad HD; Full HD; HD; Standard. Adaptive bit rate. |
| Audio Bit Rate | Self-Adaptive |
| Max. Bitrate | 2 Mbps |
| NETWORK | |
| Wi-Fi Standard | IEEE802.11b, 802.11g, 802.11n |
| Frequency Range | 2.4GHz ~ 2.4835 GHz |
| Channel Bandwidth | Supports 20MHz |
| Security | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK |
| Transmission Rate | 11b: 11Mbps,11g: 54Mbps,11n: 144Mbps |
| Wi-Fi Pairing | AP pairing |
| Protocol | Ezviz cloud proprietary protocol |
| Interface Protocol | Ezviz cloud proprietary protocol |
| Wired network | RJ45 × 1(10M/100M Adaptive Ethernet Port) |
| FUNCTION | |
| Smart Alarm | Motion detection |
| Two-way Talk | Supports |
| General Function | Anti-Flicker, Dual-Stream, Heart Beat, Mirror Image, Password Protection, Watermark |
| STORAGE | |
| Local Storage | MicroSD card slot (Max. 256 GB) |
| Cloud Storage | Ezviz cloud storage |
| GENERAL | |
| Operating Conditions | -4°F to 122 °F (-20ºC to 50ºC ); Humidity 95% or less ( non-condensing) |
| IP Grade | IP67 |
| Power Supply | DC 12V/1A |
| Power Consumption | Max. 6.0W |
| Product Dimensions | 72 × 84 × 152 mm (2.83 × 3.31 × 5.98 inch) |
| Product Weight | 253g |
| Packaging Dimensions | 227 × 100 × 92 mm (8.94 × 3.94 × 3.62 inch) |
| Mass of unit packed | 273g |
| Warranty | 12 months limited Manufacturer’s warranty |
WHAT'S IN THE TWIN PACK:
| EZVZ OutPro Camera | |
| - Drill Template | |
| - Screw Kit | |
| - Waterproof Kit | |
| - Power Adapter | |
| - Regulatory Information | |
| - Quick Start Guide | |
