PRODUCT INFORMATION
The Securi-Prod Lithium 14.6VDC 3Amp Backup Power Supply provides faster charging to 12V 7AH LifePO4 Lithium Batteries other than the traditional panel charger.
APPLICATION:
- Charging of any 12V 7AH Lithium LifePO4 Battery
- CCTV battery backup
- Alarm Panel battery backup
- Access Control battery backup
- Magnetic and Bolt lock battery backup
CAUTION – THE POWER SUPPLY IS ONLY SUITABLE FOR 12V 7A LiFePO4 BATTERIES AND NOT FOR LEAD ACID AND GEL BATTERIES.
FEATURES OF THE SECURI-PROD LITHIUM BACKUP POWER SUPPLY + 12V 7AH LiFePO4 LITHIUM BATTERY:
SECURI-PROD LITHIUM BACKUP POWER SUPPLY
- Supply battery backup in the event of load shedding or general power failures
- High current charging, less than 4 hours on standard 12v 7ah LiFePO4 Battery
- Also has a BMS wake-up feature from low voltage disconnect protection
- Constant Current – Constant voltage charging algorithm
- Furthermore, the unit has a lockable steel enclosure
SECURI-PROD 12V 7AH LiFePO4 LITHIUM BATTERY:
- Rechargeable when flat.
- The battery can be used as a backup power in the event of power failures and load shedding.
- Maintenance free, thus no maintenance required.
- Sealed battery can be placed horizontally or vertically when being installed.
- CE Approved
SPECIFICATIONS OF THE SECURI-PROD LITHIUM BACKUP POWER SUPPLY + 12V 7AH LiFePO4 LITHIUM BATTERY:
| SECURI-PROD LITHIUM BACKUP POWER SUPPLY | |
| Input Voltage Range | 110 – 240VAC |
| Input Frequency Range | 50 – 60Hz |
| Output Voltage | 14.6V ± 0.5V DC |
| Output Rated Current | 3A |
| Output Rated Power (Total) | 73W |
| Output Efficiency (Typ.) | ≥82% |
| Status/Relay Monitor | AC fail relay and buzzer |
| Charging Voltage | Voltage 14.6V ± 0.5V DC |
| Charging Current | 2A. CC-CV Only for LiFePO4 Battery |
| Protection Input | 2A / 250VAC fuse |
| Protection Battery Low Voltage | 12.2V ± 0.2V DC. PSU shuts down until AC power recovers |
| LiFePO4 Battery wake-up | ≥ 300S |
| Protection Short Circuit | Recovers automatically after fault condition is removed |
| Environment Working Temperature | 20 - 50℃ |
| Environment Storage Temperature | -30 - 80℃ |
| Environment Working Humidity | 20 - 80%RH |
| Environment Storage Humidity | 10 - 90%RH |
| EMC Standards | EN 55022: 2010, EN 55024: 2010, EN 61000-3-2: 2014, EN 61000-3-3: 2013 |
| LVD Standards | EN 60950-1: 2006 + A11: 2009 +A1: 2010 +A12: 2011 +A2: 2013 |
| Product Material | Metal Box with Key (Green branding for model differentiation) |
| Product Dimension | 203mm x 163mm x 74mm |
| Product Weight | 1.3kg |
| SECURI-PROD 12V 7AH LiFePO4 LITHIUM BATTERY | |
| Brand | Securi-Prod |
| Technology | Lithium |
| Type | Rechargeable |
| Approval | CE Approved |
| Nominal voltage | 12 Volt |
| Capacity | 7.2 Amp hours |
| Terminal | T1/T2 |
| Dimensions for battery casing | 151mm x 65mm x 95mm |
| Dimensions incl. terminals | 151mm x 65mm x 101mm |
| Battery weight | 2.36Kg |
| Warranty | 12 months limited Manufacturer’s warranty |
| GENERAL | |
| Packaging dimensions | 230mm x 180mm x 90mm |
| Mass of unit packed | 4Kg |
HANDLING AND STORAGE
- Keep the battery in a clean and dry space if and when stored
- Keep out of direct sunlight
- Keep the terminals protected and covered when being stored
- Keep out of reach of children and pets
- Do not submerge battery in water
- Do not expose battery to an open flame or extreme temperatures
- Do not crush or disassemble
- Avoid short circuits
- Store at 50% capacity, recharge every 3 months if not in use
WARNINGS:
- The Securi-Prod 3Amp Lithium Backup Power Supply + 12V 7AH LifePO4 Lithium Battery must be used for the purpose it was intended for. Ensure that the battery is fully charged when stored. The Power Supply is not suitable for Lead Acid and Gel Batteries.
WHAT’S IN THE BOX:
1 x Securi-Prod 3Amp Lithium Backup Power Supply
1 x Securi-Prod 12V 7AH LifePO4 Lithium Battery
