PRODUCT INFORMATION
The Securi-Prod Resettable Green Call Point is a vital component in fire alarm systems operating on an access control maglock system. The green manual call point acts as a door release button to be used in the event of an emergency.
When pressed, the manual call point quickly releases the secured door, allowing the occupants to exit the building with ease.
Due to the resettable feature of the Call Point the unit can easily be reset after activation, allowing for multiple uses, and minimizing the need for replacements.
FEATURES OF THE GREEN CALL POINT:
- Mechanical emergency door release switch
- Surface mount box with conduit knockout
- Manual key resettable actuator
- Push-point activation
- Includes hinged clear plastic protective cover
- Distinct green color enhances visibility, making it easily identifiable in emergency situations
- Green finish distinguishes the device from a fire alarm call point
- Dual Relay
SPECIFICATIONS OF THE GREEN CALL POINT:
| Material | ABS Fireproof Material |
| Color | Green |
| Product Type | Manual Call Point |
| Mounting | Surface Mount |
| Current Rating | 2A at 36V DC maximum |
| Operating Voltage | 12VDC |
| Dual Relay | Yes |
| Product Dimensions | 86mm (L) x 86mm (W) x 55mm (H) |
| Product Weight | 200g |
| Packaging Dimensions | |
| Mass of unit packed | |
| Warranty | 12 months limited manufacturer’s warranty |
WHAT’S IN THE BOX:
1 x Securi-Prod Resettable Green Call Point
Limitations:
The images shown are for illustrative purposes only. Actual product may vary slightly.
