Sherlo Tronics Battery Backup Power Supply 12V 3.2 Amp

R 490.00 Incl. VAT
| /

Sherlo Tronics Battery Backup Power Supply 12V 3.2 Amp

R 490.00 Incl. VAT
| /

description
Overview:
The intelligent power supply or battery charger unit is designed to meet with international safety and certification standards.
The unit has under and over voltage protection and is double fuse-protected. A truly great new product for all your 12V battery backup systems.

Features:
  • Microprocessor controlled charging output
  • Low battery switch off at 10V DC
  • Buzzer tones on battery low and AC Fail
  • Resettable Fuse protection on output
  • Fuse protection on AC input
  • Resettable Fuse protection on output

Applications:

  • Alarm panel Battery backup
  • CCTV Battery backup
  • Backup power supply for door controller.
  • Magnetic lock for an Access Control solution

Specifications:

  • Input Voltage Range: 110V ~ 230V AC 50Hz
  • Output Voltage: 13V ~ 14.4V Adjustable
  • Max Current output: 3.2A DC / 40Watts
  • Relay contact rating: 10A
  • AC Fail output rating: 140mA Positive switching
  •  ABS Plastic enclosure
  • Compatible batteries: 12V 7AH, 7.2AH & 8AH
  • Operating temp: -3°C to 60°C
  • Dimensions: 200mm(L) x 180mm(W) x 87mm(H)
  • Gross Weight: 0.895Kg
  • Warranty: 12 Months.

Certifications:

  • EN 55022:2010;   EN 55024:2010
  • EN 6100-3-2:2006+A1:2009 + A2:2009
  • EN 6100-3-3:2008;   IEC 60950-1:2005 + A1:2009

Note:

  • Battery not included, sold separately
